DH13000E – DH22000E Open-Frame Diesel Generators
Three open-frame diesel models with 2V88, 2V92 and 2V95 engines.
- Models
- DH13000E, DH15000E, DH22000E (3 models)
- Rated output
- 10 – 16 kW
- Maximum output
- 10.5 – 16.5 kW
- Rated AC voltage
- 110 / 220 / 380 V
- Starting system
- Electric start
Overview
DH13000E, DH15000E and DH22000E use 2V88, 2V92 and 2V95 engines, respectively. All three have electric start and a 30 L tank, with output specified separately for the 50 Hz and 60 Hz versions.
Specifications
| Model | DH13000E | DH15000E | DH22000E |
|---|---|---|---|
| Maximum output | 10.5 / 11.5 kW | 11.5 / 12.5 kW | 15.5 / 16.5 kW |
| Rated output | 10 / 11 kW | 11 / 12 kW | 15 / 16 kW |
| Rated AC voltage | 110 / 220 / 380 V | ||
| Phase | Single-phase or three-phase | ||
| Frequency | 50 / 60 Hz | ||
| Engine speed | 3000 rpm | 3000 / 3600 rpm | |
| Power factor | 1.0 | ||
| DC output | 12 V / 8.3 A | ||
| Alternator type | Self-excited, 2-pole, single alternator | ||
| Starting system | Electric start | ||
| Noise level (dB at 7 m) | 80 dB | 82 dB | 85 dB |
| Fuel tank capacity | 30 L | ||
| Continuous running time | 10 h | 9 / 8.5 h | 8 / 7.5 h |
| Engine model | 2V88 | 2V92 | 2V95 |
| Displacement | 912 cc | 997 cc | 1247 cc |
| Bore × stroke | 88 × 75 mm | 92 × 75 mm | 85 × 88 mm |
| Fuel consumption rate | 295 g/kWh | < 250 / 260 g/kWh | |
| Fuel type | 0# or −10# light diesel oil | ||
| Lubrication oil volume | 3 L | 3.8 L | |
| Combustion system | Direct injection | ||
| Standard features | Voltmeter, AC output socket, AC circuit breaker, oil alert | ||
| Optional features | Four side wheels, digital meter, ATS remote control | ||
| Packing dimensions (L × W × H) | 885 × 655 × 890 mm | 935 × 675 × 975 mm | |
| Net weight | 197 kg | 207 kg | 235 kg |
| Gross weight | 202 kg | 212 kg | 240 kg |
| 20' container loading | 42 pcs | 40 pcs | |
| 40' HQ container loading | 132 pcs | 82 pcs | |
Paired values are shown in 50 Hz / 60 Hz order. Use the values for the frequency specified in your order.
Sound figures are values listed in the model source. Compare the same load, measurement method, distance and environment; request the complete test conditions when they are not stated here. Fuel-consumption and runtime figures are values listed in the model source. Request the load point, fuel or tank basis and test conditions for a like-for-like comparison; actual consumption and operating time depend on the operating conditions.
Application ideas
DH13000E – DH22000E application contexts
Explore common operating environments and share the connected equipment, duty cycle and site conditions with your inquiry.
Operate outdoors with clear ventilation, stable grounding, safe exhaust direction and required working clearances.
Questions about DH13000E – DH22000E
Short answers for comparing this configuration before quotation.
Send your requirementsWhich model should I choose?
Rated output is 10 / 11 kW for DH13000E, 11 / 12 kW for DH15000E and 15 / 16 kW for DH22000E, in 50 Hz / 60 Hz order. Send your load list for selection.
How does this range differ from DH11000E–DH12000E+?
This range uses 2V88, 2V92 and 2V95 engines. DH11000E and DH12000E+ use the 1100F and 1103F engines, respectively.
Is ATS remote control available?
ATS remote control is optional. Include your site transfer arrangement so the required equipment and wiring can be confirmed.
